*A generic lockout/tagout procedure that reads "turn off power and apply lock" is not compliant, and it is not safe. OSHA's Control of Hazardous Energy standard (29 CFR 1910.147) requires documented, equipment-specific procedures that identify every energy source, every isolation point, and every step needed to achieve a verified zero-energy state. Yet inadequate or missing written procedures remain one of the most frequently cited LOTO violations year after year. This guide walks you through the process of writing machine-specific LOTO procedures that satisfy the regulation and actually protect the people using them.*
## What OSHA Actually Requires
Before writing anything, it helps to understand what the standard demands. Paragraph 1910.147(c)(4)(i) requires that procedures be developed, documented, and utilised for the control of potentially hazardous energy [1]. Each procedure must clearly and specifically outline the scope, purpose, authorisation, rules, and techniques for controlling hazardous energy, along with the means to enforce compliance.
Paragraph 1910.147(c)(4)(ii) lists the minimum elements each procedure must address:
- A specific statement of the intended use of the procedure
- The specific procedural steps for shutting down, isolating, blocking, and securing machines or equipment
- The specific procedural steps for the placement, removal, and transfer of lockout/tagout devices, and responsibility for them
- The specific requirements for testing to verify the effectiveness of isolation [2]
The word "specific" appears repeatedly for good reason. A procedure that could apply to any machine in your facility does not meet the standard. The procedure must be tailored to the particular equipment, its specific energy sources, and the actual isolation devices installed on it.
There is one exception: OSHA does permit a single procedure to cover multiple machines where those machines have the same type and magnitude of energy, the same or similar control measures, and the same procedural steps [3]. A plant with ten identical hydraulic presses, for example, might use one procedure for all ten - provided they are genuinely identical in energy configuration.
## Step 1: Survey the Equipment
The foundation of every machine-specific procedure is a thorough equipment survey. This is not a desk exercise - it requires physically walking to the machine, tracing every energy source, and documenting every isolation point.
### Identify All Energy Sources
OSHA defines hazardous energy broadly. Your survey must cover electrical energy (mains supply, battery backup, capacitors), mechanical energy (rotating parts, flywheels, springs), hydraulic energy (pressurised fluid in lines, cylinders, accumulators), pneumatic energy (compressed air in lines, receivers, actuators), thermal energy (hot surfaces, steam lines, heated dies), chemical energy (reactive substances, process chemicals), and gravitational energy (suspended loads, raised platforms, elevated components) [4].
The most dangerous procedures are those that miss a secondary energy source. A packaging machine might have an obvious electrical supply but also a pneumatic actuator fed by a separate air line. A conveyor system might be electrically driven but have a gravity-loaded section that can release when the drive is disconnected. Every source must be found and documented.
### Map Each Isolation Point
For each energy source, identify the specific isolation device - the circuit breaker, disconnect switch, valve, or other mechanism that physically separates the equipment from the energy supply. Record its type, location (building, floor, room, panel designation), and any identifying labels or numbers.
For stored energy sources, document the method for dissipation: which bleed valves to open, which pressure gauges to check, which mechanical supports to install.
### Photograph Everything
A written description of an isolation point is useful. A photograph of it is transformative. Including images of each isolation point - showing its exact location, its labelling, and the correct lockout device to use on it - dramatically reduces the chance of a technician locking out the wrong breaker or missing a valve.
This is particularly valuable in complex facilities where multiple pieces of equipment share electrical panels, or where isolation points are located at a distance from the equipment being serviced.
## Step 2: Structure the Procedure Document
A well-structured procedure document should include the following sections.
### Header Information
Every procedure needs clear identification: the equipment name and asset number, the location, the procedure reference number, the revision date, and the name or role of the person who approved it. This header information is what links the procedure to the annual periodic inspection requirement under 1910.147(c)(6).
### Scope and Purpose
A brief statement describing what the procedure covers and when it should be used. For example: "This procedure covers the isolation and lockout of the ABC-100 Hydraulic Press in Building 3, Bay 7, for all servicing and maintenance activities."
### Energy Source Summary
A table or list of every energy source associated with the equipment, the type of energy, the isolation point, and the lockout device required. This gives the technician an at-a-glance overview before they begin the step-by-step sequence.
### Step-by-Step Lockout Sequence
This is the core of the procedure. Each step should be numbered and written in clear, imperative language. A typical sequence follows the structure mandated by 1910.147(d):
**Preparation** - Identify the equipment, review the procedure, gather required lockout devices, notify affected employees.
**Shutdown** - Shut down the equipment using the normal stopping procedure. Never start the lockout sequence while the machine is running.
**Isolation** - For each energy source, in the order specified: switch off, close, or disconnect the energy-isolating device and apply a lockout device and personal padlock. Where multiple energy sources exist, the order of isolation matters and should be explicitly stated.
**Stored energy dissipation** - For each source of stored or residual energy: bleed pressure, discharge capacitors, lower loads, release springs, or otherwise render the stored energy safe. Document the specific actions and the indicators to check (pressure gauges reading zero, loads resting on mechanical supports, etc.).
**Verification** - Attempt to start the equipment using normal operating controls. Confirm zero-energy state at each isolation point. Return operating controls to the off position after testing.
### Step-by-Step Restoration Sequence
The procedure must also document how to safely restore energy after servicing is complete. This includes confirming all tools and materials are removed, all guards are reinstalled, all employees are clear of the equipment, removing lockout devices in the reverse order of application, and notifying affected employees that the equipment is being re-energised.
## Step 3: Review and Approve
No procedure should be deployed without review. As a minimum, the review should involve the person who wrote it (typically a maintenance engineer or safety professional), an authorised employee who regularly works on the equipment (to verify the steps are practical and accurate), and a safety manager or supervisor who can confirm regulatory compliance.
This review process serves as a quality check before the procedure goes live. It also builds buy-in - technicians are far more likely to follow a procedure they helped develop than one handed down from an office they have never visited.
## Step 4: Deploy and Train
A procedure sitting in a binder that nobody reads is not compliant. The standard requires that procedures be "utilised" - meaning they must be actively used during servicing and maintenance activities [5]. Employees must be trained on each procedure relevant to their work, and that training must be documented.
Deployment means making the procedure accessible at the point of work. For paper-based systems, this typically means laminated copies at the LOTO station nearest the equipment. The challenge, of course, is keeping those copies current.
## Step 5: Keep Procedures Current
This is where most programmes fail over time. Equipment changes, isolation points are relocated, new energy sources are added during modifications, and the procedure drifts out of alignment with reality. The annual periodic inspection required by 1910.147(c)(6) exists precisely to catch this drift - but it can only catch problems if the inspection is actually comparing the written procedure against the current equipment configuration.
Every time equipment is modified, relocated, or replaced, the corresponding LOTO procedure must be updated. Every time the periodic inspection identifies a deviation, the procedure must be corrected. And every time a procedure is updated, affected employees must be retrained.
## The Digital Advantage: Equipment-Based Procedures in Zentri
The process described above is sound but manually intensive. Writing, reviewing, deploying, training, and maintaining hundreds of machine-specific procedures across a facility - or across multiple sites - is a significant administrative burden. This is exactly the problem that [Zentri](https://www.zentri.cc) was designed to solve.
Zentri's equipment-based lockout instructions allow you to define isolation points directly on each equipment record - including the energy type, location, isolation device, required lockout device, and a photograph of each point. When a technician creates a lockout plan for that equipment, the isolation points automatically populate from the equipment record. There is no hunting through binders, no risk of using an outdated procedure, and no chance of missing an isolation point that was added since the last paper revision.
Critically, technicians can also add or modify isolation points on a specific lockout plan where the situation demands it - for example, when a non-standard configuration requires an additional isolation. This flexibility exists within the digital framework, so every modification is logged and traceable.
Each procedure goes through Zentri's approval workflow before deployment, ensuring that the review and sign-off step is formally completed and recorded. Photo-verified steps guide technicians through the correct sequence in the field, and every execution generates a time-stamped audit trail.
When equipment changes, updating the procedure in Zentri means every future lockout plan for that equipment automatically reflects the change. There is no print-and-distribute cycle, no risk of outdated copies in the field, and no gap between the update and its deployment.
## The Bottom Line
Writing machine-specific LOTO procedures is not glamorous work, but it is the foundation of every compliant energy control programme. A procedure that accurately reflects the equipment, clearly guides the technician through each step, and stays current over time is the single most effective tool for preventing hazardous energy incidents.
Proper LOTO procedures are estimated to prevent 120 fatalities and 50,000 injuries annually [6]. Every procedure you write is a direct investment in the safety of the people who use it.
**Ready to see equipment-based lockout procedures in action?** [Book a free Zentri demo](https://www.zentri.cc/demo) and we will walk you through how digital procedure management works for your facility.
---
### References
1. OSHA Standard 29 CFR 1910.147(c)(4)(i) - [osha.gov](https://www.osha.gov/laws-regs/regulations/standardnumber/1910/1910.147)
2. OSHA Standard 29 CFR 1910.147(c)(4)(ii)
3. OSHA Compliance Directive CPL 02-00-147, Section IX
4. OSHA Control of Hazardous Energy Overview - [osha.gov](https://www.osha.gov/control-hazardous-energy)
5. OSHA Standard 29 CFR 1910.147(c)(4)(i)
6. OSHA Control of Hazardous Energy Overview - [osha.gov](https://www.osha.gov/control-hazardous-energy)
